camera Exam-دوربین های معاینه



دوربین های معاینه

دوشنبه ۰۴ خرداد ۱۳۹۴ , ۱۵:۵۸:۲۳ بعد از ظهر

دوربین معاینه  Horus scope





  • قابلیت تعویض لنز های متعدد جهت کاربری های متفاوت
  • قابل حمل و بهترین گزینه برای استفاده در تله مدیسین
  • دارای رزولوشن Full HD جهت نمایش و ضبط تصاویر
  • دارای تصویر Real time و قابل نمایش برروی 2 نمایشگر مجزا -PCومانیتور
  • قابلیت ارسال اطلاعات بصورت وایرلس به تجهیزات همراه
  • Multi - Function Interchange Lense
  • portable for mobile medicine
  • Full HD digital image record
  • Real time Dual- Display on Pc and Monitor
  • Wireless Transmit data to the mobile device





DIGITAL HAND - HELD    DIAGNOSTIC SET

Easy take - Easy Record - Easy Communication

Multi - Function Interchange Lense

1080P & 3.5" Fullcolor LCD display

Gonioscope

General Scope





























A
Dermatoscope Otoscope   Digital Endoscope Fundus Scope 25 / 40







دوربین معاینه  Dino Lite





  • دوربین های  مخصوص معاینه چشم ، گوش ، پوست ، دهان و دندان
  • قابل حمل و بهترین گزینه برای استفاده در تله مدیسین
  • دارای رزولوشن 1.3 مگاپبکسل جهت نمایش و ضبط تصاویر
  • دارای تصویر Real time و با قابلیت ضبط تصاویربر روی PC
  • دارای نرم افزار مخصوص جهت نصب بر روی کامپیوتر
  • دارا قدرت بزرگ نمایی از 10X تا 200X
  • دارای گارانتی 1 سال تعویض
  • ساخت تایوان



aaaaaaaaaaaaaaaaaaaa







دوربین معاینه چشم

  Electronic Iriscope  PUK-2005
 :Scientific Instrument
Max. 1.30 MB Resolution (1280X1024) ; Viewable Magnification Ratio 10-30X -

:Product Specifications

("Image Sensor: 1.30 Mega pixels (1/4-
Video Capture Resolution 1280x1024, 640x480, 320x240-
Still Image Capture Resolution: Max. 1280x1024-
Viewable Magnification Ratio 10-20X-
Video format: AVI format-
White Balance: Automatic-
Exposure: Automatic-
(Light Source: 2 LED Fine Tuned White Light (Adjustable-
(Power supply: 5V DC from USB Port (No need for external Power-
(Size: 130mm (L) X30mm (R-

:System Requirements

OS: Windows 7/8/XP SP2/Vista and Vista SP1 And MAC OS-
CPU: Pentium IV 1.0G, Celeron, AMD Athlon-
CD-ROM-
Available USB 2.0 port-
256MB RAM-
100MB available hard disk space-
Graphic card: 16-bit-

:Accessories

User Guide-
(CD ROM (Manual, Application and Driver-
Gift Box-






















دوربین معاینه پوست

  Electronic Skin Scope PUK-2001W
 :Scientific Instrument
(;Max. 1.30 MB Resolution (1280X1024-
Magnification Ratio 10-60X and 230X-
 (>= 17” LCD Display); 60-230X (Recommend Specific Stand for Subtle Studying)-

:Specifications

(SB 1.1 & 2.0 Avialble (Universal Serial Bus -
(”Image Sensor: 1.30 Mega pixels (1/4-
Video Capture Resolution 1280x1024, 640x480, 320x240-
Still Image Capture Resolution: Max. 1280x1024-
Focus Range Manual Focus From 10mm to infinitive-
Frame Rate Max. 30f / s Under 600 Lux BrightnessMagnification Ratio 10-60X and 230X
 (>=  17” LCD Display); 60-230X (Recommend Specific Stand for Subtle Studying)-
White Balance: Automatic-
Exposure: Automatic-
(Light Source: 8 LED Fine Tuned White Light (Adjustable-
OSD Language: Support multi-languages, English for default-
(Power supply: 5V DC from USB Port (No need for external Power-
(Size: 102mm (L) X30mm (R-

Image Editing and Measurement Software

Edit the text on the pictureV-
Draw line and measure the length-
Draw circle with radius and measure the area of the circle-
Draw circle with diameter and measure the area of the circle-
Draw circle with three point and measure the area of the circle-
Draw rectangle and measure the area of the rectangle-
Draw angle and measure the degrees on angle-
Draw the polygon and measure the area in polygon-
























  Electronic Otoscope PUK-2004
 :Scientific Instrument

Max. 1.30 MB Resolution (1280X1024) ; Viewable Magnification Ratio 10-50X-

:Product Specifications

(”Image Sensor: 1.30 Mega pixels (1/4-
Video Capture Resolution 1280x1024, 640x480, 320x240-
Still Image Capture Resolution: Max. 1280x1024-
Viewable Magnification Ratio 15-60X-
Video format: AVI format-
White Balance: Automatic-
Exposure: Automatic-
(Light Source: 4 LED Fine Tuned White Light (Adjustable-
(Power supply: 5V DC from USB Port (No need for external Power-
(Size: 127mm (L) X30mm (R-

:System Requirements

OS: Windows 7/8/ XP SP2/Vista and Vista SP1 And MAC OS-
CPU: Pentium IV 1.0G, Celeron, AMD Athlon-
CD-ROM-
Available USB 2.0 port-
256MB RAM-
100MB available hard disk space-
Graphic card: 16-bit -

:Accessories

-User Guide-
(CD ROM (Manual, Application and Driver-
Gift Box-
Eartips (L,M,S) 3 sizes , 4pcs for each-

دوربین معاینه گوش
























دوربین معاینه دهان و حلق



Electronic Throat PUK-2006
:Scientific Instrument

USB Digital Throat Scope
Max. 1.30 MB Resolution (1280X1024) ; Viewable Magnification Ratio 10-30X

:Product Specifications

(”Image Sensor: 1.30 Mega pixels (1/4-
Video Capture Resolution 1280x1024, 640x480, 320x240-
Still Image Capture Resolution: Max. 1280x1024-
Viewable Magnification Ratio 10-20X-
Video format: AVI format-
White Balance: Automatic-
Exposure: Automatic-
(Light Source: 8 LED Fine Tuned White Light (Adjustable-
(Power supply: 5V DC from USB Port (No need for external Power-

:System Requirements

OS: Windows 7/8/XP SP2/Vista and Mac OS-
CPU: Pentium IV 1.0G, Celeron, AMD Athlon-
CD-ROM-
Available USB 2.0 port-
256MB RAM-
100MB available hard disk space-
Graphic card: 16-bit -

:Accessories

User Guide-
(CD ROM (Manual, Application and Driver-
Gift Box-






























دوربین معاینه دندان

Electronic Dental Scope PUK-2007
:Scientific Instrument

USB Digital Dental-Scope
( ; Max. 1.30 MB Resolution (1280X1024
Viewable Magnification Ratio 10-30X

:Product Specifications

(”Image Sensor: 1.30 Mega pixels (1/4-
Video Capture Resolution 1280x1024, 640x480, 320x240-
Still Image Capture Resolution: Max. 1280x1024-
Viewable Magnification Ratio 10~20X-
Video format: AVI format-
White Balance: Automatic-
Exposure: Automatic-
(Light Source: 8 LED Fine Tuned White Light (Adjustable-
(Power supply: 5V DC from USB Port (No need for external Power-
(Size: 102mm (L) X30mm (R-

:System Requirements

OS: Windows 7/8/ XP SP2/Vista and MAC OS-
CPU: Pentium IV 1.0G, Celeron, AMD Athlon-
CD-ROM-
Available USB 2.0 port-
256MB RAM-
100MB available hard disk space-
Graphic card: 16-bit-

:Accessories

User Guide-
CD ROM (Manual, Application and Driver)-
Gift Box-


















دوربین میکروسکوپ

Electronic Eyepieces PUK-2002B
:Scientific Instrument
Electronic Eyepieces
Max. 2.0 MB Resolution

Product Specifications

Image Sensor: 1/3” CMOS, 2.0 Mega pixels-
;Image Resolution: 1600 * 1200, 15 frames / sec-
    640 * 480, 30 frames / sec-
Capture images with high resolution-
Color Reproduction is good-
Exposure: Automatic-
White Balance: Automatic-
Contrast, Brightness, Saturation, and many other parameters of Software-
     Automation-
USB2.0, Plug and Play-
Eyepiece Dimension: 23mm,23.5mm,30.5mm,31.0mm-
( Power supply: 5V DC from USB Port (No need for external Power-
(Size: 55.7mm (L) X31.5mm (D-

:System Requirements

OS: Windows 7/8/XP SP2/Vista and Vista SP1,MAC OS-
CPU: Pentium IV 1.0G, Celeron, AMD Athlon-
CD-ROM-
Available USB 2.0 port-
256MB RAM-
100MB available hard disk space-
Graphic card: 16-bit-

:Accessories
User Guide-
CD ROM-
Gift Box-
USB Cable-
